2-port 4K 60Hz (3840 x 2160) 1x Typ-C "in" and 1x DisplayPort "in" to DP1.2 "out" Cable KVM Switch w/ Audio & Mic with Wired Flipper Button
The 2-port compact 1x Typ-C "in" and 1x DP1.2 "in" to DP1.2 "out" USB 4K 60Hz “Cable 2-port KVM Switch” with 2 sets of fixed KVM cables and a wired QuickSwitch! button for easy connection to your two computers. It allows you to access, control, boot and reboot one Typ-C computer and one DisplayPort computer with only one USB keyboard, mouse, DisplayPort display and an extra set of speakers. For easy and fast switching between two computers, you can use either keyboard hotkeys, the QuickSwitch! button or the Switching Software Client installed on your PCs!
- 1 x wired QuickSwitch button for instant switching between two computers
- 1 x fixed Type-C KVM and audio/mic Combo cable to PC2
- 1 x fixed DP, USB and audio/mic Combo cable to PC1
- Windows and Mac switching software support
- USB 2.0 hub ports for keyboard, mouse or other high-speed USB devices
- Digital video up to 3840x2160 / 4K @ 60 Hz (2560x1600, 1080p / Full HD etc.)
- Independent / simultaneous switching of PC and audio/mic ports
- User-definable hotkeys and universal hotkeys for computer switching
- LED indicators for easy status monitoring
Technical note: A USB 3.2 Gen 2 is required to transfer images from the USB-C.
Only this supports the necessary DP Alt Mode and works with USB-C docking stations.
Specifications:
| Model No. |
UPC-TA2 |
| Product Description |
2-Port Type-C "in" plus DP "in" to "DisplayPort 1.2" out Cable KVM Switch w/ Audio & Mic |
| Number of Ports |
2 |
| Number of Console |
1 |
| Console Keyboard Connector |
USB 2.0 Type A Female |
| Console Mouse Connector |
USB 2.0 Type A Female |
| Console Video Connector |
DP Female |
| Console Audio/Mic Connector |
2 x 3.5mm Audio/Mic Jack Female |
| PC Keyboard Connector |
Type-C Male to PC2
------------------------------
USB to PC1 |
| PC Mouse Connector |
same connector, than for keyboard used |
| PC Video Connector |
same connector, than for keyboard used |
| PC Audio/Mic Connector |
2 x 3.5mm Audio/Mic Jack Female |
| PC USB Port |
same connector, than for keyboard used |
| PC selection |
QuickSwitch! button / Hotkeys/Switching Software for Windows & Mac |
| PC port LED |
2 x Orange |
| Digital Display Resolution |
up to 3840 x 2160 with 60 Hz |
| Cables |
1 x fixed 1.2M Type-C KVM & audio/mic,
1 x fixed 1.2M DP, USB & audio/mic,
1 x 1.5M QuickSwitch! Button |
| Keyboard & Mouse Emulation |
Yes |
| Operation Temperature |
0 ~ 40 °C |
| Storage Temperature |
-20 ~ 60 °C |
| Humidity |
0 ~ 90 % RH, Non-Condensing |
| Power type |
USB interface power |
| Weight |
900 g |
| Dimension(L×W×H) |
97 x 83 x 25 (mm) |
| Safety / Emission |
FCC, CE |
B2B Product - Designed for use in a commercial environment.
