The KA7183 KVM Adapter empowers any Aten Cat 5 KVM switch* to connect to and manage aUSB-C compatible target computer. Via just a singleUSB-C plug, it is able to connect a target computer while fulfilling keyboard, video, mouse, andvirtual media or smart card / CAC reader functions.
Advanced features provided by KA7183 include superior signal compensation and delay skew technologies for greatly enhanced video quality, as well as its user-friendly, compact and lightweight design.
*Please refer to the KVM Adapter Cable Compatibility List (https://www.aten.com/global/en/products/kvmtool/kacablecompatibility/) for details.
Connects any Cat 5 KVM switch to a target computer via a singleUSB-C*
Superior video quality – supports Full HD resolution of up to 1920 x 1200**
Auto Signal Compensation (ASC) – no DIP switch setting needed for different distances
Keyboard and mouse emulation – keeps the server functioning smoothly when it’s disconnected from the switch's KVM port or is relocated to a different KVM port
Virtual media support***
Smart card / CAC reader support***
Built-in ASIC for greater stability and compatibility
Supports hot-plugging
Compact size
Upgradeable firmware
*Please refer to the KVM Adapter Cable Compatibility List (https://www.aten.com/global/en/products/kvmtool/kacablecompatibility/) for details.
**This maximum resolution may vary depending on the transmission distance.
***For more details, please refer to the product pages of the connecting KVM switches.
Package Contents
1x KA7183 USB-C Virtual Media KVM Adapter
1x USB holder kit
1x user instructions
Connectors
Link
1 x RJ-45 Female
Computer
1 x USB Type C Male
LEDs
Link
1 (Green)
Power
1 (Orange)
Power Consumption
DC5V:2.61W:12BTU
Environmental
Operating Temperature
0-50°C
Storage Temperature
-20–60°C
Physical Properties
Housing
Plastic
Weight
0.07 kg ( 0.15 lb )
Dimensions (L x W x H)
9.10 x 5.60 x 2.12 cm
(3.58 x 2.2 x 0.83 in.)
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
