3-Port 4K 1x USB-C plus 2x DP/USB Hybrid KVM-Switch with USB 3.0 support, Aten CS1953

3-Port 4K 1x USB-C plus 2x DP/USB Hybrid KVM-Switch with USB 3.0 support, Aten CS1953

The ATEN CS1953 is a hybrid KVMP™ Switch that integrates USB-C device and DisplayPort PC into a desktop workstation. Taking a giant step forward from prior digital-interfaced KVM models, the CS1953 comes with USB Type-C functionality that transfers video, audio, data, and even provides USB Power Delivery 3.0 for USB-C device charging. That means with a single USB-C cable, users can reduce bulky cable setups and experience a better working environment.

Complying with DisplayPort 1.2 standard, the CS1953 supports superior video quality up to 4K DCI (4096 x 2160 @ 60Hz) for premium images. In addition, its USB-C channel supports DP Alt Mode, so it can deliver DisplayPort signals and work like a standard DisplayPort connection. For added flexible usage, the CS1953 can convert signals from DisplayPort to HDMI or DVI with its DisplayPort Dual-Mode technology (DP++).

Featuring these robust functionalities and an unbeatable combination of USB 3.1 Gen 1 data transfer speed convenience, bus-powered design, and user-friendly port switching methods including hotkeys, mouse and remote port selector etc., the CS1953 allows users to keep up with the latest innovations in desktop multimedia and work smarter than ever.

USB-C for Space-Cost Efficiency

The CS1953 boasts the increasingly popular USB-C interface to facilitate a plug-n-play connection to mobile devices (laptops, tablets, smartphones) without going through a docking station, making it a true space and money saver for your desktop workspace.
Technical note: A USB 3.2 Gen 2 is required to transfer images from the USB-C.
Only this supports the necessary DP Alt Mode and works with USB-C docking stations.

DisplayPort for Exceptional AV Performance

The CS1953 supports DisplayPort connectivity between up to two computers, a monitor, and a mobile device (over USB-C). It brings 4K superior viewing quality to your desktop, revealing all your visual content, text and numerical digits in outstanding precision.

Plug In, Power On

By enabling the USB-C device power delivery 3.0 standard, your mobile devices start charging upon connection to the CS1953, elevating your desktop productivity with even quicker mobility.

• One USB keyboard, mouse and one DisplayPort monitor control two DisplayPort computers, one USB-C device and share two USB peripherals
• Supports superior video quality – up to 4K DCI (4096 x 2160 @ 60Hz)
• Provides USB Power Delivery 3.0 for USB-C device charging up to 45W¹
• Computer selection via pushbuttons, hotkeys, mouse², and remote port selector
• Built-in 2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates
• Supports DisplayPort Alternate Mode (DP Alt Mode) which enables the USB connection to carry DisplayPort signals
• Independent switching of KVM, USB peripheral, and audio focus³
• DisplayPort 1.2 compliant; HDCP 1.4 compliant
• Supports HD Audio³
• Supports DisplayPort Dual-Mode technology (DP++)⁴
• Firmware upgradeable
• Bus-powered⁵

  Note:
  1. An additional power adapter is needed on the CS1953 for USB-C device charging to work.
  2. Mouse port switching is only supported under mouse emulation mode with a USB 3-button mouse wheel.
  3. HD audio through DisplayPort channel cannot be switched independently.
  4. DisplayPort Dual-Mode technology (DP++) does not require an active adapter for most single display setups. Active DisplayPort adapters are recommended if you are unsure of the video source’s DP++ compatibility.
  5. The unit can be bus-powered by the connected KVM sources via USB ports.

Package Contents:

• 1x CS1953 3-Port USB-C DisplayPort Hybrid KVMP™ Switch
• 2x DisplayPort 1.2 Cables
• 2x USB 3.0 Type-A to Type-B Cables
• 1x USB-C Cable
• 3x Audio Cables
• 1x Remote Port Selector
• 1x User Instructions
• 1x Power Adapter*
